Work tank inner size (W x D)1135 x 890 mm

Max.size of workpiece(W x D xH)-Submerge790 x 550 x 250 mm

Max. size of workpiece (W x D xH)- Flushing790 x 550 x 300 mm

Max. weight of workpiece - Submerge790 kg

Max. weight of workpiece - Flushing930 kg

Axis travel (X x Y x Z)600 x 400 x 300 mm

Auxiliary table travel (U x V axis)80 x 80 mm

Wire diameterØ0.15-Ø0.3 mm

Taper angle / thickness±20° / 80 mm

Machine tool dimensions (W x D x H)2400x2930x2185 mm

Machine tool weight4830 kg

Power consumption (3 Ph. 50/60 Hz)13 kva

Dielectric fluid capacity840 liters

Max. Machining current40A
